Intelligent Time Relay

Features

  • High brightness two-color LED display
  • Multiple time ranges(4 ranges)
  • High timing precision
  • Press key setting, multiple output mode
  • Buzzer operating warning



Model Number Structure

Model Number Legend-Time Relay



Specifications

Power Supply 50Hz/60Hz AC220V/110V ± 10% or 85~265VAC/DC, DC12V, DC24V
Power Consumption ≤4.5W
Accuracy ± 0.01%
Reset Time < 0.1s
Contact Load AC250V 10A resistive load
Environment Temperature 0 ℃ ~ +50℃
Working Life Electrical Life 105 times under rated circumstance
Mechanical Life Over 108 times(at the frequency of 1.8k times per hour without load)



Relays Working Mode Introduction

Mode Code Operating Mode of Relay
H-. On; d-. Off When the meter works, relays operate while reaching the setting value.
H-. Off; d-. Off When the meter doesn't work(make it work through "reset" button or reset terminal), relays operate while reaching the setting value.
H-. On; d-. On When the meters works, relays operate. While reaching the setting value, relays release.
H-. Off; d-. Off When the meters doesn't work(make it work through "reset" button or reset terminal), relays operate. While reaching the setting value, relays release.



Connection Diagram

Connection Diagram-Time Relay



Outside Dimensions and Mounting

Outside Dimensions and Mounting-Time Relay
